Figure 35 View Comm Failures Menu - RC Systems ViewSmart 1600+ Operation Manual

Ch.01:4
Ch.02:6
Ch.03:7
Ch.04:2
Ch.05:4
Ch.06:3
Ch.07:6
Ch.08:7
Comm Port 1
Comm Port 2
Comm Port 3
4.5.3.1.2.2 Clear Failure Counts
Selecting this option clears the communication failure counter so test can be run or old data can be cleared
after communication ports are configured.
4.5.3.2 Channel Configuration
To configure a channel for Modbus® input use the Up, Down, Left and Right buttons to highlight the
desired channel, and press Edit. Use the Down button to highlight the Data From menu, and press Edit.
Pressing Edit on the Src menu item choose between Modbus® 16 Bit, Modbus® 16 Bit Signed and Modbus®
32 Bit.
UM-1097
Revision B
Ch.09:0
Ch.10:0
Ch.11:0
Ch.12:0
Ch.13:213
Ch.14:200
Ch.153:215
Ch.16:204
Cyan Comm Port 4
Orange Ethernet Port
Magenta Channel Off
Figure 34 View Comm Failures Menu
Blue
Yellow
Grey
45
