RC Systems ViewSmart 1600+ Operation Manual page 101

Standard N/A
Relay 3
State
Fault Relay N/A
State
Horn Relay N/A
State
Warmup N/A
Standard N/A
Relay 1
Flashing
Standard N/A
Relay 2
Flashing
Standard N/A
Relay 3
Flashing
Fault Relay N/A
Flashing
Horn Relay N/A
Flashing
Channel Data
UM-1097
Revision B
112022 112022 N/A
112023 112023 N/A
112024 112024 N/A
112025 112025 N/A
112026 112026 N/A
112027 112027 N/A
112028 112028 N/A
112029 112029 N/A
112034 112034 N/A
2 N/A Off = 0, On = 1, doesn't take
into account failsafe
2 N/A Off = 0, On = 1, doesn't take
into account failsafe
2 N/A Off = 0, On = 1, doesn't take
into account failsafe
2 N/A Not in warmup = 0
In warmup = 1
4 N/A False = 0, True = 1. Indicates
whether standard relay 1
has been acknowledged.
4 N/A False = 0, True = 1. Indicates
whether standard relay 2
has been acknowledged.
4 N/A False = 0, True = 1. Indicates
whether standard relay 3
has been acknowledged.
4 N/A False = 0, True = 1. Indicates
whether the fault has been
acknowledged.
4 N/A False = 0, True = 1. Indicates
whether the horn relay has
been acknowledged.
91
