Standard Relay 1 - RC Systems ViewSmart 1600+ Operation Manual

Security N/A
Unlock

Standard Relay 1

Type Channel First
A1 Votes N/A
A2 Votes N/A
A3 Votes N/A
Acknowledge N/A
Failsafe N/A
Zone 1 N/A
Enable
Zone 2 N/A
Enable
Zone 3 N/A
Enable
UM-1097
Revision B
40099 40099 N/A
Last Block
Size
40100 40100 N/A
40101 40101 N/A
40102 40102 N/A
40103 40103 N/A
40104 40104 N/A
40105 40105 N/A
40106 40106 N/A
40107 40107 N/A
3 6 This register must be written
with the Modbus® unlock
code before any parameter
can be written using function
codes 6 or 16. 0000 – 9999,
1234
Read Write Notes
FC FC
3 6, 16 Alarm 1 channels required. 0 -
16
3 6, 16 Alarm 2 channels required. 0 –
16
3 6, 16 Alarm 3 channels required. 0 -
16
3 6, 16 Relay is acknowledgeable. No
= 0, Yes = 1
3 6, 16 Relay is failsafe. No = 0, Yes =
1
3 6, 16 Use zone 1 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 2 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 3 channels for
voting. No = 0, Yes = 1
