RC Systems ViewSmart 1600+ Operation Manual page 118

Failsafe N/A
Zone 1 N/A
Enable
Zone 2 N/A
Enable
Zone 3 N/A
Enable
Zone 4 N/A
Enable
Zone 5 N/A
Enable
Zone 6 N/A
Enable
Zone 7 N/A
Enable
Zone 8 N/A
Enable
Override 1 N/A
Channel
Override 1 N/A
Alarm
UM-1097
Revision B
40184 40184 N/A
40185 40185 N/A
40186 40186 N/A
40187 40187 N/A
40188 40188 N/A
40189 40189 N/A
40190 40190 N/A
40191 40191 N/A
40192 40192 N/A
40193 40193 N/A
40194 40194 N/A
3 6, 16 Relay is failsafe. No = 0, Yes =
1
3 6, 16 Use zone 1 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 2 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 3 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 4 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 5 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 6 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 7 channels for
voting. No = 0, Yes = 1
3 6, 16 Use zone 8 channels for
voting. No = 0, Yes = 1
3 6, 16 Create an override channel. 0
is disabled. 0 - 16
3 6, 16 Alarm
channel to use.
Alarm 1 = 0,
Alarm 2 = 1,
Alarm 3 = 2
for this override
