RC Systems ViewSmart 1600+ Operation Manual page 123

Setpoint 1-16
Setpoint 1-16
Latching 1-16
Trip 1-16
On Delay 1-16
Off Delay 1-16
Horn Drive 1-16
Alarm 2
Setpoint 1-16
Setpoint 1-16
Latching 1-16
Trip 1-16
On Delay 1-16
Off Delay 1-16
Horn Drive 1-16
UM-1097
Revision B
41809 41840 2
41937 41968 2
42065 42080 1
42129 42144 1
42193 42208 1
42257 42272 1
42321 42336 1
42449 42480 2
42577 42608 2
42705 42720 1
42769 42784 1
42833 42848 1
42897 42912 1
42961 42976 1
3 16 Integer and divisor
3 16 32bit IEEE Float
3 6, 16 No = 0, Yes = 1
3 6, 16 Low = 0, high = 1
3 6, 16 Time in seconds. 0 – 10
3 6, 16 Time in minutes. 0 - 120
3 6, 16 No = 0, Yes = 1
3 16 Integer and divisor
3 16 32bit IEEE Float
3 6, 16 No = 0, Yes = 1
3 6, 16 Low = 0, high = 1
3 6, 16 Time in seconds. 0 – 10
3 6, 16 Time in minutes. 0 - 120
3 6, 16 No = 0, Yes = 1
113
