4.7 Embedded Webpage

All ViewSmart 1600+ controllers come standard with an embedded webpage. The webpage gives remote
access to view and configure parameters inside the controller. There are two levels of security clearance.
The first level allows the user to view channel status and configuration while the second level allows the
user to change configuration parameters directly from the computer.
The webpage requires a modern web browser. Supported browsers include Internet Explorer 8*, Google
Chrome, or Mozilla Firefox 2+. Viewing pages in an outdated browser will result in improperly drawn
pages.
In order to view the webpage first the user must know the IP address or, if DHCP enabled, the controller's
hostname. This information can be viewed from the Network Settings Menu. Once the name or address
is entered into a browser a pop up box ask the user for the username and password. The name and
password are fixed. The default NAME: admin and the PASSWORD: controller64. After access is gained
the user will be able to see channel data, event logs and configuration. If a parameter needs to be changed
the user must enter the Modbus®/Web Code before the controller will accept the change. The default
Modbus® Lock Code is 1234. The login username, password and Modbus®/Web Code can be changed in
the Security menu found in the Main Menu under Modbus® Lock Code.
* Internet Explorer does not allow access to hostnames that contain a '_' character.
