4.5.3.1.1.6.1 FAULT Transmit
When set to Yes the ViewSmart 1600+ broadcasts the Fault alarm flag out of the communication port.
This option is only available if Sympathy Enabled is set to Yes.
4.5.3.1.1.6.2 A1 Transmit
When set to Yes the ViewSmart 1600+ broadcasts the alarm 1 alarm flag out of the communication port.
This option is only available if Sympathy Enabled is set to Yes.
4.5.3.1.1.6.3 A2 Transmit
When set to Yes the ViewSmart 1600+ broadcasts the alarm 2 alarm flag out of the communication port.
This option is only available if Sympathy Enabled is set to Yes.
4.5.3.1.1.6.4 Sympathy A2 Ack
When set to Yes the ViewSmart 1600+ broadcasts the alarm acknowledge flag to acknowledge all ST-90
relays on the network configured to be acknowledgeable. This option is only available if Sympathy Enabled
is set to Yes.
4.5.3.1.1.6.5 A3 Transmit
When set to Yes the ViewSmart 1600+ broadcasts the alarm 3 alarm flag out of the communication port.
This option is only available if Sympathy Enabled is set to Yes.
4.5.3.1.1.7 Radio Setup
Radio Setup is used to configure radio kits that are connected directly to the ViewSmart 1600+ (Chapter
4.5.6).
4.5.3.1.1.8 Slave Byte Order
If Modbus® Slave is selected, a BYTE ODER entry appears in the menu. Slave Byte Order determines Word
and Byte alignment of data at the remote Modbus® transmitter when sending its 4 byte IEEE Floating
Point values. With the select bar on this entry, Edit toggles between the 4 possible modes. Min / Max Raw
values are not used in this mode.
4.5.3.1.1.9 Wireless Timeout
If Wireless Monitor is selected, a Wireless Timeout entry appears in the menu. The Edit button toggles
between 1m, 6m, 12m, and 18m. These represent the number of minutes the ViewSmart 1600+ will wait
before going into Comm Error.
