transmits between 4.0mA and 5.0mA for five seconds depending on remaining sensor life where 4.0mA =
0% and 5.0mA = 100% remaining sensor life. The ViewSmart 1600+ reads this value and records it as the
channel's Sensor Life. Sensor Life is stored in the ViewSmart 1600+ Modbus® database and displayed as a
bar-graph in the Sensor Info screen. This is a useful tool for planning sensor replacement schedules.
UM-1097
Revision B
Figure 54 Sensor Life Transmission Diagram
75
