eBOX671-521-FL Series user's Manual
 Flexible I/O Window
 Default : 2 x DB9 half cut bracket
 Optional I/O kits via mPCIE interface
 Indicator

1 x Green LED as indicator for PW R status
 1 x Green LED as indicator for HDD active
 4 x Green LED as indicator for programmable

Switch

1 x ATX PW R switch
 1 x Remote PW R switch
 1 x AT/ATX Quick switch
 1 x Reset switch
 Antenna & SIM

4 x SMA type connector openings for antenna
 2 x Internal SIM slot
 Internal MXM Graphics Connector
 1 x MXM Type A graphics connector, MXM module max. up to 50 watt.

Optional MXM graphics kit from Axiomtek
 TPM 2.0
 1 x ST33HTPH2E32AHB4

1.2.3 System Specifications

 Watchdog Timer
 1~255 seconds or minutes; up to 255 levels.
 Power Supply
 24V DC input
 Operation Temperature
w/o MXM module mode
 -40°C to 60°C (-40°F to +140°F) (with W .T. DRAM & SSD,CPU TDP 35W )
 -40°C to 50°C (-40°F to +122°F) (with W .T. DRAM & SSD,CPU TDP 65W )
w/ MXM module mode , 35W CPU only
 -40°C to 50°C (-40°F to +122°F) (with W .T. DRAM & SSD,CPU TDP 35W )
 Storage Temperature

-40℃ ~+80℃ (-40 ºF ~ 176ºF)
 Humidity
 10% ~ 95% (non-condensation)
 Shock
 IEC 60068-2-27 (w/SSD: 50G@wall mount, half sine,11 ms duration)
 Vibration Endurance
 IEC 60068-2-64 (w/SSD: 3Grms STD, random, 5 - 500 Hz,1 hr/axis)
 Weight

4.8 kg (10.58 lb) without package
 5.6 kg (12.34 lb) with package
 Dimension
 280mm (11.02") (W ) x 210mm (8.26") (D) x 80.5mm (3.16") (H)
【Note】:
Operating temperature specification is defined by 4 channel PoE enabled for
both w/ MXM and w/o MXM graphic module modes.
