2.3 Installation of SO-DIMM

Step 1 Turn off the system and unplug the power cord.
Step 2 Loosen four screws on the top heatsink which are used to fasten the
heatsink to the chassis.
Step 3 Located the dual DDR4 SO-DIMM sockets on main board.
Step 4 Locate the memory module, insert a gold colored contact into the
socket and push the module down until it is locked in place by the two
end latches.
Step 5 Put the top cover back and fasten four screws back onto the system.
