eBOX671-521-FL Series user's Manual
2.4 Installation of Optional MXM Graphic Module
Step 1 Turn off the system and unplug the power cord.
Step 2
Located the MXM type A connector on the main board.
Step 3 Insert optional NVIDIA
fasten two screws.
Step 4 Prepare the optional heat spreader (comes with MXM module kit) and
put the grease as below red marked on the bottom side of the copper
heat spreader.
20
®
®
/AMD
MXM module kit into the connector and
Hardware Installation
