AXIOMTEK eBOX671-521-FL Series Quick Installation Manual

Installation of SO-DIMM Memory
Step 1 Turn off the system, and unplug the power adaptor.
Step 2 Loosen four screws on the top heatsink are used to fasten the
heatsink to the chassis.
Step 3 Located the dual SO-DIMM sockets on main board.
Step 4 Locate the memory module, insert a gold colored contact into
the socket and push the module two end latches till locked.
Step 5 Put the top cover back and fasten four screws back onto the
system.
Note: Please refer to the user's manual to get more detail information.
4
©Copyright 2019 Axiomtek Co., Ltd.
Version A1 May 2019
Printed in Taiwan
9416K671020E
eBOX671-521-FL Quick Installation Guide
Packing List
System Unit x 1
Quick Installation Guide x 1
DVD/CD x 1 (for Driver & Manual)
Thermal Grease x 1
Do not try to apply power to the system if any damaged components.
Dimensions
©Copyright 2019 Axiomtek Co., Ltd.
Version A1 May 2019
Printed in Taiwan
9416K671020E
Terminal Block x 1
Remote switch cable x 1
Foot Pad x 4
Screw Pack x 1
1
