Daikin VRV III REYQ8PY1 Service Manual page 413

List of Electrical and Functional Parts
Parts Name
Wired Remote
Controller
Remote
Controller
Wireless Remote
Controller
Fan Motor
Capacitor, fan motor
Motors
Drain Pump
Swing Motor
Thermistor (Suction Air)
Thermistor (for Heat
Thermistors
Exchanger High Temp.)
Thermistor (Heat
Exchanger)
Float Switch
Others Fuse
Transformer
402
Symbol
FXZQ
20MVE
M1F
C1
M1P
M1S
R1T
R3T
R2T
S1L
F1U
T1R
Model
FXZQ FXZQ
25MVE 32MVE
BRC1C61
BRC7E530W
AC 220~240V 50Hz
1 φ 55W 4P
Thermal Fuse 135°C
4.0 µ F 400VAC
AC220-240V (50Hz)
PLD-12230DM
Thermal Fuse 145°C
MP35HCA [3P080801-1]
AC200~240V
ST8601A-1 φ 4 L250
20k Ω (25°C)
ST8605-3 φ 8 L630
20k Ω (25°C)
ST8602A-3 φ 6 L630
20k Ω (25°C)
FS-0211
250V 5A φ 5.2
TR22H21R8
Si37-701
FXZQ FXZQ
40MVE 50MVE
Appendix
Remark
Option
