Daikin VRV III REYQ8PY1 Service Manual page 189

Field Setting
(18) Setting of Direct Duct Connection
This is used when "fresh air intake kit equipped with fan" is connected. The indoor fan carries
out residual operation for one minute after the thermostat is stopped. (For the purpose of
preventing dust on the air filter from falling off.)
(19) Interlocked Operation between Humidifier and Drain Pump
This is used to interlock the humidifier with the drain pump. When water is drained out of the
unit, this setting is unnecessary.
(20) Individual Setting of Ventilation
This is set to perform individual operation of heat reclaim ventilation using the remote controller/
central unit when heat reclaim ventilation is built in.
(Switch only when heat reclaim ventilation is built in.)
178
Mode No. First Code No.
15 (25)
Mode No. First Code No.
15 (25)
Mode No. First Code No.
15 (25)
Second Code No.
01
2
02
Second Code No.
01
3
02
Second Code No.
01
5
02
Si37-701
Contents
Without direct duct
connection
With direct duct
connection equipped
with fan
Contents
Individual operation of
humidifier
Interlocked operation
between humidifier and
drain pump
Contents
—
Individual operation of
ventilation
Test Operation
