Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide
To enter the 'secfg' menu shown above a user type in 'secfg' for hardware selfboot
firmware at the diagnostics command line. A menu is present to the user showing the
'secfg' options shown above. A user can change the 'secfg' parameter by entering the
option number.
The tables below provide details for each parameter of the 'secfg' options for hardware
selfboot firmware. The top right of each table has the word "
" " signifies that the option is used to configure the operating characteristics of
Configure
the device or default values of registers in the device. "
is use for display purposes and does not affect the operating characteristics of the device or
default values of registers in the device.
1
MAC Address
Description:
MAC address of the device.
2
Device ID
Description:
PCI Device ID.
3
Subsystem Vendor ID
Description:
PCI Subsystem PCI Vendor ID.
4
Subsystem Device ID
Description:
PCI Subsystem PCI Device ID.
5
WoL
Description:
A system can be configured to power-on when a Magic Packet is received.
Enable The device will assert the pme signal, to power on the system, when a
magic packet is received.
Disable Magic packets are ignored.
Note:
A driver can setup the WoL behavior of a device and the value programmed into this
location is ignored.
6
Limit WoL Speed to 10
Description:
Limit Wake on LAN (WoL) line speed.
No 10 or100 Mbits/s is used for WoL.
Yes Only 10 Mbits/s is used for WoL.
7
Wol Auto Setting
Description:
Select WOL Auto Setting
Disable (0) WOL is Disabled
Magic Packet Option selected for Magic Packet WOL.
WOL (1)
Broadcom Confidential and Proprietary
Configure
Reference
page 57
" or " ".
Reference
" signifies that the option
Configure
Configure
Configure
Configure
Configure
Configure
Configure
