Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide
e-6
Product Name
Description:
VPD Product description string.
g
Cable Sense
Description:
Enables a low power mode (IDDQ) of the chip which allows the presence of a cable to be
detected by the chip (valid for 5752M/5755M/5787M/5787FM devices). Once Cable Sense
is enabled GPIO3 will be an Energy Detect Output Pin and will be high if a cable (with a
signal present) is plugged into the RJ45 and low otherwise.
Disable (0)
Enable (1)
h
MBA Configuration
Description:
MBA Configuration
VLan Enable (1)
VLan ID (2)
MBA Hide Banner (3)
MBA Hot Key (4)
MBA Protocol (5)
MBA Config Timeout (6)
MBA Bootstrap (7)
MBA Link Speed (8)
Remove MBA Config (9)
Example: (For Hardware Selfboot firmware).
0:>secfg
1. MAC Address.........: 001018123456
2. Device Id...........: 1713
3. Sub Vendor Id.......: 14E4
4. Sub Device Id.......: 9713
5. WOL.................: Disabled
6. WOL Speed Limit 10..: Disabled
7. WOL Auto............: Disabled
8. LED mode............: PHY MODE 2
9. VPD Prod.Name and VPD-R Data: Yes
A. Super-airplane Mode: Enabled
B. MBA Configuration
C. NIC Design.........: NIC
D. L1 PLL Disable ...... No
E. Clkreq..................: Yes
x. Save & exit
----------------------------------------------- WOL Auto (option 7)-----------------------------------------_
Disable cable sense.
Enable cable sense.
Enabled / Disabled
VLan ID
Enabled / Disabled
Ctrl-B / Ctrl-S
PXE / RPL / BOOTP / ISCSI
MBA Config Timeout value
Auto / BBS / INT18 / INT19
Auto /10HD / 10FD / 100HD / 100FD
0: No
1:Yes
page 55
Broadcom Confidential and Proprietary
