Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide
PART_NUMBER
ENGINEERING_CHANGE
MANUFACTURING_ID
ASSET_TAG
FORCE_PCI
VOLTAGE_SOURCE
LED_MODE
shared_traffic, shasta_mac, wireless_combo}
MAX_PCI_RETRY
ASF
DUAL_MAC_MODE
normal: Ch.0 and Ch. 1 enableds
macb: Ch.0 enabled, Ch.1 disabled
maca: Ch.0 disabled, Ch.1 enabled
xbar: Both MACs shares one function in PCI configuration space
swapxbar :
swap: swap between Ch.0 and Ch1.
MBA_BOOT_PROTOCOL
MBA_BOOTSTRAP_TYPE
MBA_DELAY_TIME
EXPANSION_ROM_SIZE
DESIGN_TYPE
VENDOR_SPECIFIC0
VENDOR_SPECIFIC1
REVERSE_NWAY
WOL_LIMIT_10
FIBER_WOL_CAPABLE
CLOCK_RUN_SETTING
DISABLE_POWER_SAVING
HIDE_MBA_SETUP_PROMPT = {enable, disable}
MBA_SETUP_HOT_KEY
ENABLE_AUTO_POWERDOWN
CAPACITIVE_COUPLING
PRI_SMB_ADDR
SEC_SMB_ADDR
*This should only be used to select port for dual ports devices.
** This is for dual port devices only.
For Selfboot Firmware:
MAC_ADDRESS
SYSTEM_DEVICE_ID
SUBSYSTEM_VENDOR_ID
SUBSYSTEM_DEVICE_ID
WOL
WOL_LIMIT_10
DESIGN_TYPE
ENABLE_AUTO_POWERDOWN
REVERSE_NWAY
DISABLE_POWER_SAVING
CABLE_SENSE
LED_MODE
shared_traffic,
POWER_DISSIPATCHED _CONSUMED
PCIE_POWER_BUDGETING_DATA
= string (16)
= string (10)
= string (4)
= string (16)
= {enable, disable}
= {1.3, 1.8}
= {mac_mode, triple_link /phy_mode1, link_speed/phy_mode2,
= {0..7, auto}
= {enable, disable}
= {normal, mac0, mac1, xbar, swap, swapxbar} **
= { pxe, rpl, bootp, iscsi}
= {auto, bbs, int18, int19}
= {0..15}
= {64K, 128K, 256K, 512K, 1M, 2M, 4M, 8M, 16M}
= {nic, lom}
= string (16)
= string (16)
= {yes, no}
= {yes, no}
= {yes, no}
= {enable, disable}
= {yes, no}
= {Ctrl-S, Ctrl-B}
= {yes, no}
= {enable, disable}
= {Hex(value)}
= {Hex(value)}
= xx:xx:xx:xx:xx:xx
= xxxx
= xxxx
= xxxx
= {enable, disable}
= {yes, no}
= {nic, lom}
= {yes, no}
= {yes, no}
= {yes,no}
= {enable, disable}
= {mac_mode,
shasta_mac, wireless_combo}
= d0:d1:d2:d3:d4 *
= x0:x1:x2:x3:x4 **
