3.4.5

Processor COP Header

The ATCA-F140 contains a 16-pin 0.1" header for the P2020 JTAG COP header. The
following table shows the pinout assignment for the processor COP header.
Table 3-19
Contact
Number
1
3
5
7
9
11
13
15
3.4.6

Asset JTAG Header

The ATCA-F140 contains a 20-pin 0.1" header for an Asset JTAG header. The pinout for
the header is given in the following table.
Table 3-20
Contact
Number
1
3
ATCA-F140 Series Installation and Use (6806800M67S)
P8 eUSB Header Pin Assignment (continued)
Contact
Description
Number
Data+ 6
GND 8
No Pin Key 10
P50 COP Header Pin Assignment
Description
COP_TDO
COP_TDI
+3.3V pull-up
COP_TCK
COP_TMS
COP_SRESET_L
COP_HRESET_L
COP_CHKSTP_OUT_L
P12 Asset JTAG Header Pin Assignment
Description
TCK
TDO
Controls, LEDs, and Connectors
Description
No Connect
No Connect
No Connect
Contact
Description
Number
2 +3.3V pull-up
4 COP_TRST_L
6 COP_VDD_SENSE
8 COP_CHKSTP_IN_L
10 No Connect
12 COP_PRESENT_L
14 No Pin Key
16 GND
Contact
Description
Number
2 JTAG_EN_L (GND on cable)
4 GND
