AMC Connector

The following table shows the AMC connector pinout assignment.
Table 3-15
AMC Bay
Pin Signal
1 GND
2 +12V
3 PS1#
4 +3.3V IPMI
5 GA0
6 Reserved
7 GND
8 Reserved
9 +12V
10 GND
AMC_TX0+
11
(to BIX_P18)
AMC_TX0-
12
(to BIX_P18)
13 GND
AMC_RX0+
14
(to BIX_P18)
AMC_RX0-
15
(to BIX_P18)
16 GND
17 GA1
82
AMC Bay Connector Pin Assignment
Pin Signal
35 Unused
36 Unused
37 GND
38 Unused
39 Unused
40 GND
41 ENABLE#
42 +12V
43 GND
AMC_TX4+
44
(to 82571EB)
AMC_TX4-
45
(to 82571EB)
46 GND
AMC_RX4+
47
(to 82571EB)
AMC_RX4-
48
(to 82571EB)
49 GND
AMC_TX5+
50
(to 82571EB)
AMC_TX5-
51
(to 82571EB)
Pin Signal Pin Signal
AMC_RX7-
69 103
(to 82571EB)
70 GND 104
71 IPMI_SDA_L 105
72 +12V 106
73 GND 107
74 TCLKA+ 108
75 TCLKA- 109
76 GND 110
77 TCLKB+ 111
78 TCLKB- 112
79 GND 113
80 PCIe_CLK+ 114
81 PCIe_CLK- 115
82 GND 116
83 PS0# 117
84 +12V 118 Unused
85 GND 119 GND
ATCA-F140 Series Installation and Use (6806800M67S)
Controls, LEDs, and Connectors
Pin Signal
AMC_TX10+
137 GND
(to RTM)
GND 138 TCLKD-
AMC_RX11-
139 TCLKD+
(to RTM)
140
AMC_RX11+
GND
(to RTM)
GND 141 Unused
AMC_TX11-
142 Unused
(to RTM)
143
AMC_TX11+
GND
(to RTM)
GND 144 Unused
Unused 145 Unused
Unused 146 GND
GND 147 Unused
Unused 148 Unused
Unused 149 GND
GND 150 Unused
Unused 151 Unused
152 GND
153 P30_B7
