ATCA-F140-D Information

B.1

ATCA-F140-D Overview

The ATCA-F140-D is a COTS 40G Ethernet switch blade that features attachment blocks
specifically designed to enable the blade to be secured in an AXP1440-D shelf. Captive
screws on the AXP1440-D are used to securely attach the ATCA-F140-D to the backplane
for use in rugged environments. The ATCA-F140-D is electrically identical to the
ATCA-F140. References to the ATCA-F140 in this manual also apply to the ATCA-F140-D.
B.2

Mechanical

The following figures show the location of the specially designed attachment blocks,
attachment block drawings, and the captive screws in the AXP1440-D.

Figure B-1 Location of Attachment Blocks on the ATCA-F140-D

PIN1 PIN1
ATCA-F140 Series Installation and Use (6806800M67S)
ASSY#
120 240 120 240
Appendix B
Zone 3
Attachment
Block
COO LABEL
Zone 2
Attachment
Block
131
