4.8

Fabric Channel Interface

The ATCA-F140 uses Broadcom BCM56846 switch device for the fabric channel interface.
It is a high-performance 640Gbps network switch with 18 integrated warpCores (16 active).
Each warpCore has four integrated 10G SerDes allowing native support of one 40GbE or
four 10GbE ports. On the ATCA-F140, the BCM56846 is used to provide sixteen (16) 40G
ports and four 1G ports.
12 of the 40Gbps ports are routed to the backplane switch fabric support of a 14-slot
chassis. Two 40Gbps uplink interfaces from the switch are routed to the Zone 3 connectors
for use by an RTM. Two other 40Gbps uplink ports are routed to BCM84740PHYs to
provide two QSFP+ uplinks on the front panel. The P2020 service processor communicates
with the BCM56846 through the PCI Express interface to initialize and manage the switch.
Two 1G-SGMII ports are routed to the backplane for switch fabric support of the two extra
slots in a 16-slot chassis, or optionally, to the TopSync device and Fabric Channel 1. One
1G-SerDes port is routed to AMC port 1. One 1G-SGMII port is routed to update channels
3 and 4 to form a fabric switch-to-AMC cross-connect with the other switch blade across
the backplane.
Table 4-4
BCM56846 Physical Port
wc0-0
wc0-1
wc0-2
wc0-3
wc1
wc2
wc3
wc4
wc5-0
wc5-1
wc5-2
wc5-3
wc6-0
wc6-1
ATCA-F140 Series Installation and Use (6806800M67S)
Fabric Switch Mapping (Default AXP1440 Chassis Configuration)
Port Name
ge0
ge1
ge2
ge3
xe0
xe1
xe2
xe3
xe4
xe5
xe6
xe7
xe8
xe9
Functional Description
Destination
Fabric Ch 14 (LS 15)
Fabric Ch 15 (LS 16)
Backplane UC3/4
AMC Port 1
Fabric Ch 2 (LS 3)
Fabric Ch 3 (LS 4)
Fabric Ch 4 (LS 5)
Fabric Ch 5 (LS 6)
Fabric Ch 6 (LS 7)
Fabric Ch 6 (LS 7)
Fabric Ch 6 (LS 7)
Fabric Ch 6 (LS 7)
Fabric Ch 7 (LS 8)
Fabric Ch 7 (LS 8)
Front Panel Label
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
101
