ATCA-F140-TCLK3 Overview
The ATCA-F140-TCLK3 switch blade features Telecom Stratum Clocking.
A.2
Face Plate
The following figure shows the ATCA-F140-TCLK3 face plate LEDs. The tables that follow
show the connectors. Refer to
plate LEDs.
Figure A-1 ATCA-F140-TCLK3 Face Plate
AMC Bay
Out of Service LED
In Service LED
Attention LED
Fabric Uplink
QSFP+ Ports
Base Uplink
SFP+ Ports
Service Processor
Ethernet Port
Telco Clocks
2x4 RJ-45
Connectors
Hot Swap
LED
Service
Processor
Console
