Face Plate Connectors

Table A-1
RJ-45 Pin
1
2
3
4
5
6
7
8
Table A-2
RJ-45 Pin
1
2
3
4
5
6
7
8
126
Master/Slave Sync Connector (J12-Upper 1)
Function
Transmit +
Transmit -
Receive +
Receive -
Inter-Shelf Connectors (J12-Lower 1, 2, 3, and Upper 2, 3)
Function
Port 1 +
Port 1 -
Port 2 +
Port 3 +
Port 3 -
Port 2 -
Port 4 +
Port 4 -
