Hardware Preparation and Installation
2.5

Blade Configuration

There are no configuration switch settings for normal operational mode. Switch changes
are for activating various debug modes. Setting any switch to the ON state may cause
unpredictable operation.
Product Malfunction
Switches marked as RESERVED may carry production-related functions and can
cause the product to malfunction if the setting is changed.
Do not change settings of switches marked as RESERVED.
Product Damage
Setting/resetting the switches during operation can cause damage to the product.
Check and change switch settings before installing the product.
Too much force may damage the reset switch.
Use minimal force when pressing the reset switch.
2.5.1

SATA Drive Installation

An optional SATA drive can be installed on the ATCA-F140. This is a 2.5 inch form factor
drive, designed for extreme temperature and vibration environments and has been tested
and approved for use on the ATCA-F140. The hard drive kits available at the time of release
include the hard drive, all required mounting hardware, and installation instructions. The
hard drive kits are listed in the respective product data sheets - refer to
135
for all related documentation.
52
Hardware Preparation and Installation
NOTICE
ATCA-F140 Series Installation and Use (6806800M67S)
Appendix C on page
