Controls, LEDs, and Connectors
Table 3-6
Contact Number
13
14
15
16
17 - 24
25
26
27
28
29
30
31
32
33
34
72
Zone 1 Connector P10 Pin Assignment (continued)
Description
IPMB Clock Port A
IPMB Data Port A
IPMB Clock Port B
IPMB Data Port A
Not used
Shelf Ground
Logic Ground
Enable B
Voltage Return A
Voltage Return B
Early -48V A
Early -48V B
Enable A
-48V A
-48V A
ATCA-F140 Series Installation and Use (6806800M67S)
Controls, LEDs, and Connectors
