2.1.9 Exiting the service mode

In order to exit the service mode, use the S
To exit the service mode, do the following:
– in the LCD keypad, keep pressing the
will appear in the upper line of the display, and then press successively the
keys;
– in the LED keypad, press the
keys.
2.2 D X program
LOAD
The D X program enables data exchange between the computer and the control panel,
LOAD
facilitates alarm system configuration, and ensures easy viewing of the status of zones,
partitions, outputs, troubles, and other components of the system. Access to the program is
protected by a code (password). To obtain access at the first run of the program, enter the
factory default code: 1234 (you need not enter the factory code, just click on the "OK"
button). It is recommended that the factory access code be changed.
Note: Entering an invalid code three times will terminate the program.
Communication between the program and the control panel is coded. The alarm control
panel may be programmed locally or remotely:
1. Local programming requires connection between the RS-232 (TTL) port on control
panel mainboard (RJ type socket) and the computer COM port. The connection should be
made by using the cable manufactured by SATEL and available in the DB9FC/RJ-KPL
set.
2. In case of remote programming, communication with the control panel can be effected:
– through the built-in 300 bps modem. This programming method requires connection
of the control panel to the telephone line. An analog modem must be connected on the
computer side.
– through the ETHM-1 module connected to the control panel. The ETHM-1 module
(with firmware version 1.04 or newer) and a computer with D
must be connected to the Ethernet network (TCP/IP protocol).
2.2.1 Main menu of the
Explanations for Fig. 3:
1 - type of alarm control panel.
2 - name of alarm system / data file.
3 - information on data writing/reading progress.
VERSA
ERV
key and then press successively the
program
D X
LOAD
Fig. 3. Main menu of D
.M function.
ODE END
key until the 0. S
X program.
LOAD
M submenu
RV OD CONFIG
X program installed
LOAD
17
