H3C SecPath V100-S Security Gateway
LED
100M
FULL
Note:
The three LEDs corresponding to each Ethernet interface are (top-down order):
LINK/ACT LED, 100M LED, and FULL LED.

1.2.4 Fixed Interface Attributes

I. Console port (CONSOLE)

Table 1-3 Attributes of the console port

Attribute
Connector
Interface standard
Baud rate
Function
II. Auxiliary port (AUX)

Table 1-4 Attributes of the console port

Connector
Interface standard
Baud rate
Function
OFF means packets are being transmitted/received at 10 Mbps on
the interface. ON means packets are being transmitted/received at
100 Mbps on the interface.
OFF means the interface is operating in half-duplex mode. ON
means the interface is operating in full-duplex mode.
RJ45
RS232
9600 bps (default) to 115200 bps
Connection to an ASCII terminal
Connection to a serial port on a local PC to run terminal
emulation program on the PC
Command line interface
Attribute
1-5
Chapter 1 Product Introduction
Meaning
Description
Description
RJ45
RS232
1200 to 115200 bps
Modem dial-up
Backup
