OPTIONAL NIGHT AIR CURTAIN INSTALLATION & OPERATING INSTRUCTIONS
Night Air Curtain Installation & Operating Instructions
1. Use caution when handling Night Air Curtain.
2. Display case may come with Night Curtain already attached. If not, a retrofit kit will be
provided. If using SCC-supplied retrofit kit, attach to display case by centering night
curtain along angled Honeycomb Support (as shown in illustration below). Attachment
Magnets will hold Night Air Curtain firmly in place.
3. Grasp the handle and pull downward to desired area OUTSIDE acrylic sneeze guard.
4. To return Night Air Curtain to its retracted position, grasp handle, lift up and away from
its magnetic attachment and carefully wind Night Air Curtain back into roll.
5. Caution! Do not allow spring-loaded Night Air Curtain to freely snap back into roll.
Doing so can eventually destroy Night Air Curtain's tension and retractability.
6. Note: Due to ONLY the magnets keeping Night Air Curtain Assembly in place, it may
be removed at any time by firmly lifting up and off Night Air Curtain Support.
7. Caution! Do not slide or drag Night Air Curtain from unit while removing. Lift
curtain straight up to avoid scratching or marring honeycomb support surface.
View of Night Air Curtain
(Topside / Attached) To
Honeycomb Support
Night Air Curtain
Retraction Magnets
Acrylic
Sneeze Guard)
Night Air Curtain
Retraction Magnets
Attachment Points
(Along Plate Outside
Acrylic Sneeze Guard)
View of Night Air Curtain
(Underside / Detached)
24
NOTE: THE
BELOW
ILLUSTRATION
MAY NOT
EXACTLY
REFLECT
EVERY
PARTICULAR
CASE'S
FEATURES
OR
OPTIONS.
Night Air Curtain
Magnets (To Retract
& Attach to Lower
Section)
Night Air Curtain
Magnets (To Hold In
Air Curtain In Place)
