START-UP AND OPERATION, CONTINUED: NIGHT AIR CURTAIN OPERATING INSTRUCTIONS

Night Air Curtain
Handle
(5) Magnets (To Hold
Night Air Curtain In
Place in Lower
Section of Case)
Underside View of
Detached Night Air Curtain
Night Air Curtain
Handle
Side View of Attached
Night Air Curtain (With
End Panel Removed)
(2) Night Air Curtain
Magnets (To Retract &
Attach to Lower Section).
One at Each End
Night Air Curtain
General Location for
Attaching Retaining
Magnets
Night Air Curtain
Projected Arc From
Lower Section
Night Air
Curtain Roller
and Housing
2. Night Air Curtain Operating Instructions
1. Use caution when handling Night Air Curtain. See view of
detached Night Air Curtain at top-left.
2. Display case comes with Night Curtain already attached.
3. Attachment Magnets will hold Night Air Curtain firmly in place.
4. Grasp the handle at lower-front-center area of case (shown in
enlarged view at lower-left) and pull upward.
5. When extended, the Night Air Curtain magnets may be attached
to metal plate in front of honeycomb (as shown below).
6. Magnets (on extended night air curtain) will hold it firmly in place.
7. To return Night Air Curtain to its original position, grasp handle,
and lift up and off from its magnetic attachment and carefully
wind Night Air Curtain back into roll (into lower section of case).
8. Caution! Do not allow spring-loaded Night Air Curtain to
freely snap back into roll. Doing so can eventually destroy
Night Air Curtain's tension and retractability.
9. Caution! Do not slide or drag Night Air Curtain across metal
plate (in front of honeycomb) when extending and attaching.
Lift end of curtain (and its magnets) straight up and off metal
housing to avoid scratching or marring surface.
18
