prox.pad Installation/Programming Manual
2.7.2
Programming Users
The following section describes in detail how to program users. The prox.pad can store up to 2000 users. Each user is stored in a
separate location in the unit's memory. This is referred to as the user location. Codes can be from 1 to 6 digit in length in any
combination. If at any point while programming a code or a card you get a programming error (solid yellow LED), and you know you
are entering the command correctly, make sure that the code or card is not already programmed. If you are unsure try entering that
code or presenting that card outside of program mode and see if you are granted access. If so, you must use a different code or card for
that user.
Note: IEI recommends that you keep a list of all the users you have programmed in the device, in case you need to modify or delete a
particular user.
Note: A minimum of three user codes must be programmed into the keypad for controlling access.
2.7.2.a
User Types
The table below identifies and describes the four user types supported by the prox.pad unit. The user type number is used in
programming commands in the subsequent sections where it indicates "user type."
User Type Name
Toggle User
Normal Access
Log Dump
Lockout
2.7.2.b
Programming a "Code Only" User
To program a "Code Only" use command 50. This user gains access by entering their code on the keypad. Refer to table 6 for details
on user types. Codes can be from 1 to 6 digit in length in any combination. The program sequence is as follows:
1. Enter Program Mode
Press: 99 # master code *
The yellow LED flashes slowly.
2. Program the "Code Only" User.
Press: 50 # user type # user location # code * repeat code *
3. Exit Program Mode
Press: *
The yellow LED stops flashing.
Page 38 of 86
Table 6: prox.pad User Types
User Type Number
0
1
2
3
Description
Toggle users are used to latch the main relay in the unlocked
position for an indefinite period of time. Entering the same (or
another) toggle code, re-locks the unit.
Normal access users are the default user type. This user type
unlocks the door for the duration of the Main Relay time set in
command 11.
Log Dump users are used to dump the transaction event log
via the IR LED. When this user type is used the log begins
transmitting immediately. The log is only dumped and is not
erased. This user type does not gain access through the door.
This user type, locks the keypad disallowing all other codes
plus the door remains in the current state. During a lockout
state, card access does not continue to work. If it is locked, it
remains locked. If it is unlocked, it remains unlocked until
another Lockout code (or the same one) is entered, releasing
it from Lockout mode.
Document # 6055676, Rev 2.2, D4b
