OVEN USE

4. CONTROL PANEL USE

Foreword:
When selecting certain functions, the initial status is restored if
no button is pressed within 15 seconds (approx.).

4.1 SWITCHING THE OVEN ON

Before using the oven, make sure:
- the external electric safety switch is on;
- the water shutoff cocks are open;
- the oven outlets are not blocked.
Switch the oven on by pressing the button I (O - I) of the following
switch:
O ° I
the start screen will appear, during which the electronic board
performs several checks.
Touch screen
Touch the symbols on the "touch screen" to select the oven
functions, setting and modifying the relevant values. It is also
arranged with a basic functions menu to simplify use, and can be
customised as required by adding or removing some functions.
The "touch screen" has a similar use to that of a cell phone and
computer, with drop-down menu and keypad for entering values.
In some cases, by touching the required symbol a screen relevant
to the symbol appears, and in others only the function is selected.
TOUCH the required part of the Display to perform any
operation, such as:
- select
- confi rm
- change screen (or Display page)

4.2 SWITCHING THE OVEN OFF

To switch the oven off, press the button O (O - I) of the following
switch:
O ° I

4.3 SELECTING CONTROLS (AREAS)

The controls are mainly divided into 5 different management areas
for the various functions. These are selected from the CONTROLS
MENU in the drop-down menu of the fi rst line of MANUAL mode.
Manual = manual cooking mode (conventional).
Automatic = automatic cooking mode
Programs = use of existing programs (or recipes) and
storing of new ones.
MT Programs = MultiTimer programs (cooking in several
times).
Cleaning = cleaning programs for oven compartment.
Settings = variation and confi guration of functions.
