PARAMETERS \ TYPE
Index
Output power (apparent / active)
GENERAL AND ENVIRONMENTAL DATA
Topology
Number of voltage phases (input / output)
2)
Housing type
Max. efficiency (for VFI)
Efficiency (for ECO)
3)
Operating temperature
Storage temperature
Relative humidity during operation
Relative humidity during storage
4)
Altitude above sea level
Protection class
Working environment
Cooling
Cooling air temperature
Radiated heat for nominal operating
conditions
INPUT
Rated voltage (effective value)
Input voltage range
(effective values) and tolerance
Rated current
Rated frequency, input voltage
Frequency range and tolerance
PF power factor
Total harmonic distortion, input current (THDi)
OUTPUT
Rated voltage (effective value)
Output voltage range (effective value) and
6)
tolerance - mains operation
Output voltage range (effective value) and
6)
tolerance - backup operation
Rated current
Output voltage waveform
(backup / mains operation)
Output voltage rated frequency
Frequency range (tolerance)
- mains operation
Frequency range (tolerance)
- backup operation
Static voltage regulation
Total harmonic distortion, output current
(THDu)
CF peak ratio
Switching time to battery mode
Switching time to return to the mains-based
operation
7)
Overload capacity
47
www.ever.eu
EVER POWERLINE RT PLUS UPS Operating Manual

TECHNICAL PARAMETERS

POWERLINE RT PLUS
1000
T/PWPLRT-111000/00
1)
1000 VA / 1000 W
87 %
< 510 BTU / h
5)
5 A
(The output voltage is adjusted from the LCD panel. The default value is 230 V AC.)
(The output voltage is adjusted from the LCD panel. The default value is 230 V AC.)
4.4 A
(Same as the input or selected for the frequency conversion mode. In such a case, a
(Same as the input or selected for the frequency conversion mode. In such a case, a
Technical Support, phone: +48 61 6500 400
POWERLINE RT PLUS
POWERLINE RT PLUS
2000
T/PWPLRT-112000/00
2000 VA / 2000 W
VFI (on-line, VFI-SS-111)
1 / 1
Rack / Tower
89 %
95 %
0 ÷ +40 °C
0 ÷ +40 °C
< 95% (no condensation)
< 95% (no condensation)
up to 1000 m
IP20
Office / industrial rooms with low level of pollution
Forced, with internal fans
< 25°C
< 850 BTU / h
230 V AC
110 ÷ 300 V AC ± 5%
9.8 A
50 / 60 Hz
40 - 70 Hz ± 5 %
≥0.99
< 10 %
230 V AC
208 V AC / 220 V AC / 230 V AC / 240 V AC ± 1 %
208 V AC / 220 V AC / 230 V AC / 240 V AC ± 1 %
8.7 A
Sine / Sine
50 / 60 Hz
50 / 60 Hz ± 0.5 %
40% power reduction occurs.)
50 / 60 Hz ± 0.5 %
40% power reduction occurs.)
± 1%
< 3% for Pmax (linear)
< 5% (non-linear according to PN-EN 62040-3)
3:1
0 ms
0 ms
105% ÷ 110% - warning
110% ÷ 120% - 60 s (switching to the bypass mode)
> 120% - 100 ms (UPS switches off)
POWERLINE RT PLUS
3000
T/PWPLRT-113000/00
3000 VA / 3000 W
90 %
< 1200 BTU / h
14.5 A
13.1 A
