5. Slide out the battery chamber and the battery (Fig. 30).
CAUTION! The battery chamber slides out completely from the module
housing. Exercise particular care when sliding it out as it is very heavy.
6. Make sure the dimensions and the type of replacement batteries satisfy the
technical parameters (are identical as the parameters of the old batteries).
Exercise special care when replacing the batteries with new ones.
7. Slide in the battery chamber with the batteries into the UPS (Fig. 30).
2019-11-25 11:43
EVER POWERLINE RT PLUS UPS Operating Manual
Fig. 29. Removing the panel
Fig. 30: Removing and installing the battery chamber
