EVER POWERLINE RT PLUS UPS Operating Manual

COMMUNICATION WITH PC

To establish communication between the PC and the UPS, the user can choose to
use the RS232 or USB interface or the Ethernet port (optional equipment).
The UPS unit is managed via remote control systems (PC or server) with PowerSoft
freeware. PowerSoft freeware is designed to enable monitoring and configuring the
UPS unit's parameters. It also features management and control functionalities
which, when combined with the UPS power supply unit, provide reliable and secure
protection against interruptions in power supply from the mains thus ensuring the
continuity of operation for unsupervised IT systems. PowerSoft also allows (from the
level of the central computer control unit) to securely shutdown other PCs within a
particular LAN network.
The PowerSoft package is compatible with a wide range of operating systems, and
this versatility should help to meet the operating requirements of a majority of small
and medium enterprises (SMEs).
Current software and installation procedures can be downloaded from
www.ever.eu.

COMMUNICATION USING RS232 OR USB HID DEVICES

The units is fitted with two data link connectors as standard, namely the
RS232 and USB. To ensure proper communication with the computer, the
installation management software will prompt the user to connect the communication
cable.
CAUTION! Only one data connector can be used at a time.

SNMP/HTTP NETWORK MANAGEMENT CARD

The network management card is optional and can be installed by the user in
service. The network card is installed in a special slot in the real panel of the UPS
unit. With the network card, the user can control the UPS from any PC in the
network. This arrangement is most typically used for central power supply systems,
or whenever there is a requirement to provide remote control for the power supply
system (e.g. if the distance between the server room and the location of the UPS unit
is considerable).
42
Technical Support, phone: +48 61 6500 400
www.ever.eu
