PARAMETERS \ TYPE
Index
Output power (apparent / active)
BATTERIES AND BACKUP TIMES
Internal batteries
Total number of internal batteries
Maximum permissible combined capacity of
internal battery pack
External battery packs
Maximum number of battery packs
Backup time using internal batteries
(100% / 80% / 50% of Pmax)
Backup time using internal batteries
+ battery module (100% / 80% / 50% of Pmax)
Rated voltage for the DC circuit
Maximum charging time for UPS internal
batteries - after batteries have been 80%
discharged
Charging current, maximum
MECHANICAL PARAMETERS
Dimensions (height. x width x depth)
8)
Weight
Weight for transporting (gross)
Dimensions for transporting (height. x width x
depth)
Position in transit
PROTECTION
Input protection
Output protection
FEATURES AND ADDITIONAL FUNCTIONS
UPS power supply connection
Output connections (socket type and quantity)
EPO / ROO
Signaling
Communication interface
RJ45 / RJ11 telecommunication filter
Monitoring and management software
STANDARDS APPLIED
Declarations
Standards
Caution: The manufacturer reserves the right to change the above listed parameters without notice.
REMARKS:
1)
To ensure normal operation of the UPS unit, the load at its output should not exceed 80% of the value given in the chart. A power
reserve is necessary to maintain continuity of operation of connected appliances in case of momentary surges of load current.
2)
The Rack Kit is optional.
3) Constant exposure of the device to environment temperature over +25°C results in reducing battery life. The recommended operating
temperature for the device is 15-25°C.
4)
Maximum allowed load the UPS unit will decrease as the altitude above the sea level increases over the specified limit.
5)
The input voltage range depends on the unit's load level:
Load 0 – 50% bottom input voltage threshold 110 V AC ± 5%
Load 50 – 60% bottom input voltage threshold 120 V AC ± 5%
2019-11-25 11:43
EVER POWERLINE RT PLUS UPS Operating Manual
POWERLINE RT PLUS
1000
T/PWPLRT-111000/00
1)
1000 VA / 1000 W
1 x 3
6 / 8 /18 min.
24 / 32 /51 min.
36 V DC
88 (2U) x 438 x 430 mm
14.5 kg
8)
16 kg
218 x 542 x 560 mm
Short circuit protection -
Automatic fuse
10 A / 250 V AC
Inverter-based operation – electronic short-circuit
protection and overload protection
1 x IEC 320 C14 (10 A)
3 x IEC 320 C13 (10A) -
controlled
3 x IEC 320 C13 (10A)
RS232, USB, SNMP / HTTP network management card (optional)
Technical Support, phone: +48 61 6500 400
POWERLINE RT PLUS
POWERLINE RT PLUS
2000
T/PWPLRT-112000/00
2000 VA / 2000 W
12 V / 9 Ah VRLA
9 Ah
Yes
10
6 / 11 / 18 min.
25 / 32 / 51 min.
≤ 3 h
1.5 A
88 (2U) x 438 x 610 mm
24 kg
26 kg
218 x 542 x 740 mm
Horizontal
Short circuit protection - Automatic fuse
16 A / 250 V AC
Against overvoltage (Anti-surge)
1 x IEC 320 C20 (16 A)
4 x IEC 320 C13 (10A) -
controlled
4 x IEC 320 C13 (10A)
Present (NC) / Present
Acoustic and visual; graphical LCD display
Card with volt-free contacts (optional)
ADSL, LAN 10/100 Base-T, Phone / Modem
PowerSoft Professional
CE
PN-EN 62040-1:2009, PN-EN 62040-2:2008
POWERLINE RT PLUS
3000
T/PWPLRT-113000/00
3000 VA / 3000 W
1 x 6
3.5 / 5 / 11 min.
14 / 22 / 32 min.
72 V DC
28 kg
30 kg
Inverter-based operation –
electronic overload
protection
Short circuit protection -
output socket protection
2 x Automatic fuse 10 A /
250 V AC
4 x IEC 320 C13 (10A) -
controlled
4 x IEC 320 C13 (10A)
1 x IEC 320 C19 (16A)
48
