REPLACING THE BATTERY IN THE UPS

CAUTION! Battery replacement can be conducted only when the UPS is
in horizontal position (Rack version). Performing the operation in any
other position may cause damage to the device.
To replace the battery inside the UPS, follow these steps:
1. Switch off the UPS unit.
2. Disconnect the UPS unit's power cord from the mains (it is NOT ALLOWED to
replace the battery when the UPS is connected to the mains).
3. Disassemble the UPS unit's front panel and the battery terminal cover.
Disconnect the battery chamber terminal from the unit's battery terminal (Fig.
25).
4. Slide out the battery chamber and the battery (Fig. 26).
CAUTION! The battery chamber slides out completely from the battery
housing. Exercise particular care when sliding it out as it is very heavy.
37
www.ever.eu
EVER POWERLINE RT PLUS UPS Operating Manual
Fig. 25. Removing the unit's panel
