STARTING UP THE UPS UNIT (power supply from the mains)

Once the UPS unit is correctly connected, start the unit by following these steps in
sequence:
1. Make sure the UPS unit's power cord is connected.
2. Switch on the UPS logically with the control panel (press the ON button and
keep it depressed for over 1 s).
3. Make sure no active alarms or messages are displayed on the screen. If any
such alarms or messages are present, check their meaning in the "Diagnostics
of errors reported by the UPS".
4. The icon
the mains (normal) mode. All devices connected to the UPS are supplied with
power and protected.

STARTING THE UPS UP FROM THE BATTERY (cold start)

To start the UPS up when there is no power in the mains (the so-called "cold start")
follow these steps:
1. Press the ON button on the UPS unit's front panel and keep it depressed to
switch the device on.
2. Switch on the UPS logically with the control panel (press the ON button and
keep it depressed for over 1 s).
3. Make sure no active alarms or messages are displayed on the screen. If any
such alarms or messages are present, check their meaning in the "Diagnostics
of errors reported by the UPS".
4. The icon
sound signal, indicates that the UPS unit operates in the backup (battery)
mode. All devices connected to the UPS are supplied with power and
protected. The time power is supplied to the receivers depends on the power
accumulated in the battery.

SWITCHING THE UPS OFF

To switch the UPS off follow these steps:
2019-11-25 11:43
EVER POWERLINE RT PLUS UPS Operating Manual
shown on the display indicates that the UPS unit operates in
shown on the display, accompanied with an intermittent
