Summary of Contents for Ever Power Systems Sinline 800
-
Page 2: Table Of Contents
SINLINE series UPS – Instruction Manual TABLE OF CONTENTS TABLE OF CONTENTS............................2 INTRODUCTION ..............................3 GENERAL INFORMATION ..........................3 PURPOSE OF THE POWER SUPPLY......................3 GENERAL FEATURES OF THE UPS ......................4 ELEMENTS OF THE SINLINE UPS - TOWER MODEL..................5 FRONT PANEL .............................. -
Page 3: Introduction
SINLINE series UPS – Instruction Manual INTRODUCTION Thank you for purchasing the EVER SINLINE UPS (UPS). It belongs to the latest series of state-of-the-art power supply devices designed to work with servers, small computer networks, as well as Tower- and Rack-type workstations. When operating in the battery mode, the UPSs of this series generate sinusoidal current at their output thanks to the Clear Digital Sinus (CDS) system and offer the feature of remote control of operating parameters via RS232 serial port. -
Page 4: General Features Of The Ups
SINLINE series UPS – Instruction Manual It is not recommended to use these UPSs to power large TV sets, laser printers and other similar devices that draw greater impulse power than the battery module is capable of providing. GENERAL FEATURES OF THE UPS •... -
Page 5: Elements Of The Sinline Ups - Tower Model
SINLINE series UPS – Instruction Manual ELEMENTS OF THE SINLINE UPS - Tower Model FRONT PANEL Fig. 1: Front panel A column of green LEDs indicating the charge level of the battery. The figure below indicates the voltage thresholds for a single battery at which individual LEDs light up. -
Page 6: Rear Panel
SINLINE series UPS – Instruction Manual If only the red LED is lit and blinking quickly (with acoustic signal) it indicates the occurrence of a short-circuit at the BACK-UP’Soutput. If only the red LED is lit (with acoustic signal) it indicates that the battery module has overloaded. -
Page 7: Elements Of The Sinline Ups - Rack Model
SINLINE series UPS – Instruction Manual ELEMENTS OF THE SINLINE UPS - Rack Model FRONT PANEL Fig. 3: SINLINE RACK 19" 2U and 3U – Front Panel 1) Circuit breaker 2) Power switch 3) Two-colour LED indicating the operation mode: a. -
Page 8: Rear Panel
SINLINE series UPS – Instruction Manual REAR PANEL Fig. 4: SINLINE RACK 19" 2U – Rear Panel Fig. 5: SINLINE RACK 19" 3U – Rear Panel 7) IEC 320 C13 outlet sockets 8) RS232 serial port for communication with a PC 9) Power cord socket 10) Telecommunications filter sockets HEALTH AND SAFETY INSTRUCTIONS... -
Page 9: Electric Safety
SINLINE series UPS – Instruction Manual ELECTRIC SAFETY • Never work alone in conditions that may be hazardous to health and/or life; • Even a momentary shorting of a strong current may lead to severe burns; • Prior to connecting the device to the mains inspect the condition of power cords, plugs and sockets, as well as the condition of the device itself;... -
Page 10: Installation
SINLINE series UPS – Instruction Manual INSTALLATION WARNING! Prior to the installation of the UPS it is crucial to familiarise yourself with the health & safety measures provided in the previous chapter. UNPACKING Please inspect the UPS upon receipt. Although the product is packed very carefully it might have sustained damage from shock during transport. -
Page 11: Installation Of The Sinline Ups - Rack Model
SINLINE series UPS – Instruction Manual INSTALLATION OF THE SINLINE UPS – Rack Model When choosing the installation spot you must take the device's weight into account. Strength of the supporting cabinet/rack is the most important. The battery module should only be used in rooms where dustiness, temperature and moisture levels conform with the device's specification. -
Page 12: Connections
SINLINE series UPS – Instruction Manual Fig. 6: SINLINE RACK 19" – Top View WARNING! The device must not be installed in the proximity of flammable materials! CONNECTIONS The mains socket the UPS is to be connected to should be located near the battery module (maximum distance –... - Page 13 SINLINE series UPS – Instruction Manual Due to the type and location of circuit breakers in the UPS, the safety circuits of the building function as one of the protection measures. This is essential to provide the UPS with shorting protection. Protection parameters of the buildings' installations should be adjusted according to the type and size of load connected to the installation.
- Page 14 SINLINE series UPS – Instruction Manual Output installation Even though the input side allows both types of terminals, the output installation arranged inconsistently with this instruction may damage the UPS. The diagram of correctly arranged output connections is presented on the scheme below. WARNING! The output side of the battery module only allows the TN-S mains configuration.
-
Page 15: First Start
SINLINE series UPS – Instruction Manual Fig. 11: The arrangement of terminals of output sockets of Rack Model Sinline battery module FIRST START WARNING! The UPS may only be connected to a ~230V mains socket equipped with a grounding bolt. Electric installation of the building to which the battery module is connected must be protected against overloads and shorting. -
Page 16: Description Of The Ups's Operation
SINLINE series UPS – Instruction Manual DESCRIPTION OF THE UPS’S OPERATION GENERAL INFORMATION The SINLINE UPS is a state-of-the-art electronic device constituting an autonomous source of true sine wave voltage of ~230V. This device belongs to the LINE – INTERACTIVE class of uninterruptible power supply devices, including the CLEAR DIGITAL SINUS (CDS) system that generates a clear voltage sinus at the battery output. -
Page 17: Mains Operation Mode
SINLINE series UPS – Instruction Manual This UPS utilises an innovative charging method reserved only for the most advanced UPSs (CBC - COOL BATTERY CHARGING). During the mains operation mode it charges the batteries and in the battery module operation mode it converts the internal energy of the battery into the alternating current to power the protected devices. -
Page 18: Safeguards
SINLINE series UPS – Instruction Manual SAFEGUARDS Against overloads Overload is signalled by constant shining of the last LED (red) in the load indication column and a continuous sound signal. If the UPS is operating in battery module mode then after a short time the overload causes the UPS to switch to emergency operation mode. -
Page 19: Communication Between The Ups And The Computer
SINLINE series UPS – Instruction Manual Table 1 ERROR TABLE Signalling Type of error Tower Model Rack Model UPS connected incorrectly Internal errors (a combination of lit LEDs indicates various errors) Information for the tech support COMMUNICATION BETWEEN THE UPS AND THE COMPUTER SINLINE series UPSs come with enhanced control features. -
Page 20: Installation And Configuration Of The Powersoft Personal Software
SINLINE series UPS – Instruction Manual INSTALLATION AND CONFIGURATION OF THE POWERSOFT PERSONAL SOFTWARE Installation on computers with Windows Prior to beginning the installation of PowerSoft: • Uninstall the current version of PowerSoft or any other control software (if the user is changing the UPS protecting the computer), •... -
Page 21: Software Updates
SINLINE series UPS – Instruction Manual rpm –ev PowerSoftpersonal-x.x.x Debian For the Debian systems the software is provided in the form of a DEB package. The software is installed with the use of the following command: dpkg –-install PowerSoftpersonal-x.x.x.deb To uninstall the application enter the following command: dpkg –-remove PowerSoft FreeBSD For FreeBSD systems the software is provided in the form of the default package... -
Page 22: Configuring The Ups's Parameters
SINLINE series UPS – Instruction Manual Linux/Unix systems For Linux/Unix systems PowerSoft can be updated by downloading the new package from www.ever.eu. For CentOS, RedHat, Suse Linux, and Fedora Core PowerSoft can be updated by entering the following command: rpm –Uv PowerSoftlite-x.x.x For Debian and FreeBSD systems we recommend uninstalling the old version and then installing the new version of the software. -
Page 23: Additional Remarks
SINLINE series UPS – Instruction Manual ADDITIONAL REMARKS CAUTION: This is a C2-category UPS. In domestic environment the product may interfere with reception of radio waves so the user may be required to implement additional preventive measures. WARNING! No service elements located inside the UPS are to be modified by the end user. -
Page 24: Storage, Maintenance And Transport
SINLINE series UPS – Instruction Manual STORAGE, MAINTENANCE AND TRANSPORT The UPS should be stored in a cool and dry place, in operating position, with batteries completely charged: • In temperatures between 0° C and +30° C the battery should be charged every 6 months;... -
Page 25: Technical Parameters - Tower Model
SINLINE series UPS – Instruction Manual TECHNICAL PARAMETERS – Tower Model PARAMETERS / SINLINE SINLINE SINLINE SINLINE SINLINE UPS TYPE 1200 1600 2000 3000 800VA/ 1200VA/ 1600VA/ 2000VA/ 3000VA/ Output power 520W 780W 1040W 1300W 1950W Working environment Office or industrial rooms with low level of pollution Operating temperature +10 ÷... -
Page 26: Technical Parameters - Rack Model
SINLINE series UPS – Instruction Manual TECHNICAL PARAMETERS – Rack Model PARAMETERS / SINLINE 1200 SINLINE 1600 SINLINE 2000 SINLINE 3000 UPS TYPE Rack Rack Rack Rack 1200VA/ 1600VA/ 2000VA/ 3000VA/ Output power 780W 1040W 1350W 1950W Working environment Office or industrial rooms with low level of pollution Operating temperature +10 ÷... -
Page 27: Information Regarding Regulations And Warranty
SINLINE series UPS – Instruction Manual INFORMATION REGARDING REGULATIONS AND WARRANTY DECLARATION OF CONFORMITY The UPS was manufactured in Poland and its structure conforms to appropriate subject matter standards. WARRANTY A separate document attached to the product constitutes the warranty. The document must meet all formal requirements (e.g.
