Fig. 14: Attaching the feet kit to the UPS and the module
4. Use the supplied plugs to cover the unused mounting openings (Fig. 15).
5. Remove the covers of the battery module sockets in the UPS and the battery
module (Fig. 16).
6. Make a connection between the UPS and the battery module with the supplied
cable. Remove the socket covers (Fig. 17).
27
www.ever.eu
EVER POWERLINE RT PLUS UPS Operating Manual
Fig. 15. Installation of plugs
Fig. 16. Removing the plugs
