005 INVERTER mode
Selecting the EPO
function (remote
006 emergency power off)
or ROO function
(remote ON/OFF)
Number of battery
007
modules
Activating the BYPASS
008 mode when the UPS is
not logically on
009 Sound signaling
Controlled output
010
sockets

PROTECTION

Overload protection

In the mains mode, the overload in the range of 105-110% is indicated by an
intermittent sound signal and message E14 on the display. If the overload condition
stays at the 110-120% level and when the function "switch to BYPASS if overloaded"
is enabled (the function can be enabled through external software), the UPS unit
switches to the bypass mode after 60 s and signals the overload (message A64).
When the overload condition ceases, the unit reverts to the mains mode. If the
function "switch to BYPASS if overloaded" is disabled, output sockets are
disconnected after 60 s. The LCD displays message E14.
21
www.ever.eu
EVER POWERLINE RT PLUS UPS Operating Manual
[dis] – Disabled
[EnA] – Enabled
EPO / ROO*
0bP / 1bP / 2bP / 3bP
/ 4bP / 5bP / 6bP /
7bP / 8bP / 9bP / AbP
[dis] – Disabled
[EnA] – Enabled
[dis] – Disabled
[EnA] – Enabled
[dis] – Disabled
[EnA] – Enabled
Technical Support, phone: +48 61 6500 400
Disabled
EPO
0
Disabled
Enabled
Enabled
