Summary of Contents for Ever Power Systems POWERLINE 11 series
-
Page 2: Table Of Contents
POWERLINE 11 series UPS – Instruction Manual TABLE OF CONTENTS TABLE OF CONTENTS............................2 INTRODUCTION ..............................3 GENERAL INFORMATION ..........................3 PURPOSE OF THE POWER SUPPLY......................3 General features of the battery back-up ........................3 UPS STRUCTURE ..............................4 FRONT PANEL..............................4 REAR PANEL .............................. -
Page 3: Introduction
POWERLINE 11 series UPS – Instruction Manual INTRODUCTION Thank you for purchasing the EVER POWERLINE battery back-up. It belongs to the latest series of state-of-the-art power supply devices designed to work with servers, computer networks, as well as data processing systems. -
Page 4: Ups Structure
POWERLINE 11 series UPS – Instruction Manual alternating charging current component, which considerably prolongs accumulators’ life. Microchip control system (DSP) enables precision and reliability of the whole power supply system. The automatic bypass system increases the overall system security. In the event of a failure of the inverter, the current from the mains will be provided directly to the load. - Page 5 POWERLINE 11 series UPS – Instruction Manual Symbol Name Description If the unit is in BYPASS mode or zero mode (STANDBY), pressing this button SELECT allows you to configure the unit’s parameters: output voltage, frequency, BYBASS mode options. To approve the selection, press ENTER (2)
-
Page 6: Rear Panel
POWERLINE 11 series UPS – Instruction Manual REAR PANEL Rear panel view of POWERLINE 6-11 and POWERLINE 10-11 back-ups 1 – Cover of the power supply and receiver grid connections 2 – Cover of the servicing BYPASS switch 3 – Input safeguard 4 –... -
Page 7: Safety And Health Instructions
POWERLINE 11 series UPS – Instruction Manual SAFETY AND HEALTH INSTRUCTIONS TRANSPORT • Due to the significant weight of the devices, special care must be taken during transport; • do not handle heavy equipment by yourself; • storage and operation of the device should take place in conditions conforming to its specification. - Page 8 POWERLINE 11 series UPS – Instruction Manual • The device receiving the current must be connected with an appropriate circuit protection (manual cut-out or circuit breaker); • The device is equipped with an earthing cable which siphons the earth leakage current to the receivers (e.g.
-
Page 9: Installation
POWERLINE 11 series UPS – Instruction Manual INSTALLATION WARNING! Before installing the battery back-up you must obligatorily familiarise yourself with the safety and health measures provided in the previous chapter. UNPACKING Please inspect the battery back-up upon receipt. Although the product is packed very carefully it could have sustained damage from shock during transport. -
Page 10: Installation Of The Battery Back-Up
POWERLINE 11 series UPS – Instruction Manual INSTALLATION OF THE BATTERY BACK-UP When choosing the installation spot you must take the device's weight into account. The back-up should only be used in rooms whose dustiness, temperature and moisture levels conform with the device's specification. In order to ensure correct operation of the back-up, appropriate cooling conditions for the device must be provided. -
Page 11: Input / Output Installation
POWERLINE 11 series UPS – Instruction Manual Input / Output Installation 1 – PE cord of the power supply line 2 – N cord of the power supply line 3 – L cord of the power supply line 4 – Jumper (parallel operation option) 5 –... -
Page 12: Description Of The Back-Up's Operation
POWERLINE 11 series UPS – Instruction Manual DESCRIPTION OF THE BACK-UP'S OPERATION GENERAL INFORMATION The POWERLINE battery back-up is a state-of-the-art electronic device constituting an autonomous source of true sine wave voltage of ~230V. This device belongs to the ONLINE-class uninterruptable power supply group, characterized by constant power processing. -
Page 13: Bypass" Mode ("01" Mode)
POWERLINE 11 series UPS – Instruction Manual “BYPASS” MODE (“01” MODE) The back-up switches to BYPASS mode in the event of inverter overload, exceeding the acceptable temperature, damage of the inverter and after turning the device off with the “0” button on the panel. In the BYPASS mode the voltage is provided to the output directly from the input line through the mechanical switch (transmitter). -
Page 14: Back-Up (Battery) Operation Mode ("03" Mode)
POWERLINE 11 series UPS – Instruction Manual The back-up is started only after pressing the “ON” button on the front panel for approx. 1 second. After the completion of diagnostics UPS is ready for operation. If the mains voltage is irregular (excessively low or high voltage, frequency outside the operating range), the unit will switch to battery mode. -
Page 15: Service Bypass" Operation Mode
POWERLINE 11 series UPS – Instruction Manual “SERVICE BYPASS” OPERATION MODE This operation mode enables the servicing of the UPS without the need to disconnect power from the receivers plugged into the UPS output. WARNING! In the service BYPASS operation mode the receivers powered by UPS output are in no way protected from power loss in the mains. -
Page 16: Safeguards
POWERLINE 11 series UPS – Instruction Manual Code Unit operational status Indication Overload in mains mode; the UPS A double sound signal every 1 second. is in BYPASS mode Overload in mains mode; the A double sound signal every 1 second. -
Page 17: Epo
POWERLINE 11 series UPS – Instruction Manual EPO (Emergency Power Off) is a mechanism that cuts off energy supply to receivers at the UPS output in extreme situations (e.g. a fire). The mechanism may be activated by short-circuiting the pins of the external EPO connector (trip). -
Page 18: Winpower Software Installation
POWERLINE 11 series UPS – Instruction Manual WinPower SOFTWARE INSTALLATION Installation on computers with Windows Prior to beginning the installation of WinPower: • Uninstall the current version of WinPower, PowerSoft or any other control software (in situations where the user is changing the battery back-up protecting the computer), •... -
Page 19: Installation And Configuration Of The Powersoft Personal Software
POWERLINE 11 series UPS – Instruction Manual INSTALLATION AND CONFIGURATION OF THE POWERSOFT PERSONAL SOFTWARE Installation on computers with Windows Before beginning the installation of PowerSoft: • Uninstall the current version of PowerSoft or any other control software (in situations where the user is changing the battery back-up protecting the... -
Page 20: Installation On Computers With Linux/Unix
POWERLINE 11 series UPS – Instruction Manual Installation on computers with Linux/Unix The binary version of the application for Linux/Unix systems is provided in the following formats: CentOS, RedHat, Suse Linux, Fedora Core For the following systems: CentOS, RedHat, Suse Linux, and Fedora Core the software is provided in the form of a RPM package. -
Page 21: Software Updates
POWERLINE 11 series UPS – Instruction Manual Starting the software After installation the system service is started automatically, while the control panel application can be found at /usr/local/powersoft. Please note that for the Polish diacritics to be correctly displayed the system locale should be Polish. -
Page 22: Additional Remarks
POWERLINE 11 series UPS – Instruction Manual ADDITIONAL REMARKS WARNING! Product for commercial and industrial applications in second environment. Applying additional preventive measures or limiters in the installation may be required in order to prevent the emission of disturbances. WARNING! No service elements located inside the battery back-up are to be modified by the end user. -
Page 23: Battery Back-Up And Power Generators
POWERLINE 11 series UPS – Instruction Manual BATTERY BACK-UP AND POWER GENERATORS The POWERLINE series battery back-ups are ONLINE-class devices. By design, the battery back-up tolerates mains voltage variations in the range of ~176÷276V, as well as frequency variations of ±4 Hz with respect to the nominal frequency of 50 Hz. -
Page 24: Technical Parameters
POWERLINE 11 series UPS – Instruction Manual TECHNICAL PARAMETERS INSTALLATION GUIDELINES PARAMETER / UPS POWERLINE 6 1/1 POWERLINE 10 1/1 Apparent / active power 6 kVA / 4.2 kW 10 kVA / 7kW POWER SUPPLY PARAMETERS Power supply system layout... -
Page 25: Technical Data
POWERLINE 11 series UPS – Instruction Manual TECHNICAL DATA PARAMETERS / MODEL POWERLINE 6-11 POWERLINE 10-11 Output power 6 kVA / 4.2 kW 10 kVA / 7kW Working environment Office or industrial rooms with low level of pollution Operating temperature 0 ÷... -
Page 26: Diagnostics Of Errors Reported By Ups
POWERLINE 11 series UPS – Instruction Manual DIAGNOSTICS OF ERRORS REPORTED BY UPS Possible cause Solution Make sure that the unit is not overloaded, the fans are not The unit switched to an blocked, and the surrounding temperature is not excessively Error code “08”,continuous... -
Page 27: Information Regarding Regulations And Warranty
POWERLINE 11 series UPS – Instruction Manual INFORMATION REGARDING REGULATIONS AND WARRANTY DECLARATION OF CONFORMITY The UPS structure conforms with applicable subject norms. WARRANTY A separate document attached to the product constitutes the warranty. The document must meet all formal requirements (e.g. the fields: serial number, model/type, date of sale, and dealer stamp must be filled out).
