Table 1. Functions of the control panel buttons
Button
Function
Switching the unit on
logically
ON
Battery test start
"Cold start". Starting
the UPS without the
mains voltage.
Switching the unit off
OFF
logically
Access the UPS
unit's main menu
Scrolling the menu
ENTER
up
Confirming the
current setting and
exiting the menu.
Changing the
parameter's value
Exiting the menu
without saving the
changes.
ESC
Switching the sound
signal on / off
ENTER
+
Bypass mode on / off
ESC
ON
+
Rack / Tower mode
ENTER
15
www.ever.eu
EVER POWERLINE RT PLUS UPS Operating Manual
When the UPS is not on logically (not operating in back-up or normal mode),
press and keep the button depressed for over 1 second to switch the unit on
logically.
Press and keep the button depressed for over 5 s to start the battery test. The
function is only available in the mains, ECO or inverter (frequency converter)
mode.
To start the UPS up when there is no voltage in the mains press and keep this
button depressed for over 1 s.
When the UPS is on logically, press and keep the button depressed for over 1 s
to switch the unit off logically (power supply to receiver's connected to the UPS's
output is switched off).
Press and keep this button depressed for over 5 s to enter the unit's main menu.
The function is only available in the bypass or standby mode.
Press this button quickly to navigate to the next menu.
Press and keep this button depressed for over 5 s to exit the menu and to confirm
the currently entered setting.
Press the button shortly to change the value of the edited parameter, without
saving it.
Press and keep this button depressed for over 5 s to exit the menu without
confirming the currently entered changes.
Press and keep the button depressed for over 5 s to switch the sound signal on /
off.
This applies to sound signals if the UPS operates in the backup mode or low
battery condition is reported. Sound signals are active in the remaining cases
(despite previous deactivation).
When the UPS operates in the mains mode, press ENTER and ESC
simultaneously and keep these buttons depressed for over 5 s to switch the unit
from the mains mode to the bypass mode or from the bypass mode to the mains
mode.
Press simultaneously and keep depressed the ON and ENTER buttons for over 5
s to change the LCD orientation (Tower / Rack).
Technical Support, phone: +48 61 6500 400
