7. Connect the battery module detection cables and the cables supplying power
to the internal charger of the battery modules (Fig. 18).
CAUTION! After switching the UPS on, use its menu to configure the
number of connected battery modules (1 - 10).
RACK VERSION UPS INSTALLATION
CAUTION! Taking into account the considerable weight of the device,
we recommend that two persons work together to install the UPS in the
rack cabinet.
CAUTION! To ensure optimal cooling conditions, we recommend that
some free space is left above the UPS.
2019-11-25 11:43
EVER POWERLINE RT PLUS UPS Operating Manual
Fig. 17. Installation of plugs
Fig. 18: Connecting the UPS and the modules
Technical Support, phone: +48 61 6500 400
28
