7 Software interface

The FALCOM JP7-T family supports NMEA-0183 and SiRF binary
protocols. A short description of these protocols are provided herein.
For more detailed information please refer to the SiRFstarII message set
specification available in the section "service/downloads/manuals" at
FALCOM homepage.

7.1 SiRF binary data message

Table 7 lists the message list for the SiRF output messages.
Hex ASCII
0 x 02 2
0 x 03 3
0 x 04 4
0 x 06 6
0 x 07 7
0 x 08 8
0 x 09 9
0 x 0A 10
0 x 0B 11
0 x 0C 12
0 x 0D 13
0 x 0E 14
0 x 0F 15
0 x 10 16
0 x 11 17
0 x 12 18
0 x 13 19
0 x 14 20
0 x 1C 28 Nav. Lib. Measurement Data
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
Name
Measured Navigation Data
True Tracker Data
Measured Tracking Data
SW Version
Clock Status
50 BPS Subframe Data
Throughput
Error ID
Command
Acknowledgement
Command No
Acknowledgement
Visible List
Almanac Data
Ephemeris Data
Test Mode 1
Differential Corrections
Ok To Send
Navigation Parameters
Test Mode 2
Description
Position, velocity and time
Not implemented
Satellite and C/No information
Receiver software
Current clock status
Standard ICD format
Navigation complete data
Error coding for message failure
Successful request
Unsuccessful request
Auto Output
Response to Poll
Response to Poll
For use with SiRFtest (Test Mode 1)
Received from DGPS broadcast
CPU ON/OFF (Trickle Power)
Response to Poll
Additional test data (Test Mode 2)
Measurement Data
