5 SOFTWARE INTERFACE

The NAVI-XS POI evaluation receiver is capable of outputting data in the NMEA-0183
format as defined by the National Marine Electronics Association (NMEA), Standard
for Interfacing Marine Electronic Devices, January 1, 1997.

5.1 NMEA output messages

The table below shows all NMEA output messages supported by NAVI-XS POI as well
as a brief description of each output message.
For more detailed information about the output message list, please refer to the
SiRFstarII message
"support/downloads/documentation/SiRF" on Falcom's Website
Option
GGA
GLL
GSA GPS receiver operating mode, satellites used in the position solution and DOP values.
GSV The number of GPS satellites in view satellite ID numbers, elevation, azimuth and SNR values.
RMC
Table 5:
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
set specification
Time, position and fix type data.
Latitude, longitude, UTC time of position fix and status.
Time, date, position, course and speed data.
NMEA Output Messages
available
:
Description
V 1.00
ERSION
in section
www.falcom.de.
Page 27
