FALCOM JP7-T Series Hardware Description page 26

GPS-RECEIVER JP7-T
Ball Name
1 GPIO1
2 GPIO0
3 GPIO7
4 GPIO5
5 GPIO6
6 GPIO10
7 RESET_N
8 V_BAT
9 VC3.0
10 V_ANT
11 RF_GND
12 RF_GND
13 RF_IN
14 GND
15 GND
16 GND
17 GND
18 GND
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
26 GND
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
I/O Description
I/O See chapter
I/O See chapter
I/O See chapter
I/O See chapter
I/O See chapter
I/O See chapter
I Reset the unit, if Active Low
I Power for RTC and SRAM
O Supply voltage of RF section
I Power supply for an active
antenna
Analog ground
Analog ground
I GPS signal from connected
antenna
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
VERSION 1.02
Level
6.8.4 CMOS
6.8.4 CMOS
6.8.4 CMOS
6.8.4 CMOS
6.8.4 CMOS
6.8.4 CMOS
CMOS
+3 V DC ±5%
+ 3.0 V DC /
max. 25 mA
Up to +12 V DC /
max. 25 mA
50 Ohms @ 1.575
Page 26
GHz
