0.2 Scope of the user's manual

This document describes the hardware interface and the technical
specifications of the JP7-T.
It is also the preliminary data sheet for the electrical and mechanical device
application design.
As far as JP7-T family concept is concerned, there are three different JP7-T
GPS Receiver Modules available. The difference between these receivers
can be recognised by looking on the bottom side of the module (see attached
picture on the chapter 0.5 "Order option").
To choose a unit it depends on the customer requirements:
JP7-T
RF Part
TCXO 25.5535 MHz 25.5535 MHz
Active
antenna power built in
control
RF connector Not available
Digital Part
Connector Not available
Balls Not available
In this manual user will not find separately description for each option of
devices. The interfaces, pin-out and some application's example are the
same for all devices.
