FALCOM JP7-T Series Hardware Description page 35

GPS-RECEIVER JP7-T
Hex ASCII
0 x 1D 29
0 x 1E 30
0 x 1F 31 Nav. Lib. Initialization Data
0 x FF 255
Table 7:
Table 8: lists the message list for the SiRF input messages.
Hex ASCII
0 x 55 85
0 x 80 128
0 x 81 129
0 x 82 130
0 x 84 132
0 x 85 133
0 x 86 134
0 x 87 135
0 x 88 136
0 x 89 137
0 x 8A 138
0 x 8B 139
0 x 8C 140
0 x 8D 141
0 x 8E 142 Steady-State Detection – not
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
Name
Nav. Lib. DGPS Data
Nav. Lib. SV State Data
Development Data
SiRF Output Messages
Name
Transmit Serial Message
Initialize Data Source
Switch to NMEA Protocol
Set Almanac (upload)
Software Version (Poll)
DGPS Source Control
Set Main Serial Port
Switch Protocol
Mode Control
DOP Mask Control
DGPS Mode
Elevation Mask
Power Mask
Editing Residual
used
Description
Differential GPS Data
Satellite State Data
Initialization Data
Various status messages
Description
User definable message
Receiver initialization and
associated parameters
Enable NMEA message, output rate
and baud rate
Sends an existing almanac file to the
receiver
Polls for the loaded software version
DGPS correction source and beacon
receiver information
Baud rate, data bits, stop bits and
parity
Obsolete
Navigation mode configuration
DOP mask selection and parameters
DGPS mode selection and timeout
value
Elevation tracking and navigation
masks
Power tracking and navigation
masks
Not implemented
Not implemented
VERSION 1.02
Page 35
