5.4.3 DC input signals

VCC (Pin 58 and 60)
VANT (Pin 59)
GND

5.4.4 General purpose input/output (Pin 51, 53, 54 and 56)

Several I/O's of the CPU are connected to the hardware interface connector
of the FALCOM C2D-SI. They are reserved for customer specific
applications.

5.5 Software interface

The GPS core in the FALCOM C2D-SI supports NMEA-0183 and SiRF
binary protocols. A short description of these protocols are provided herein.
For more detailed information please refer to the SiRFstarII message set
specification available in the section "service/manuals" of the FALCOM
homepage.

5.5.1 SiRF binary data message

Hex ASCII
0 x 02 2
0 x 03 3
0 x 04 4
0 x 05 5
0 x 06 6
0 x 07 7
