FALCOM JP7-T Series Hardware Description page 29

GPS-RECEIVER JP7-T
PIN Name
15 V_BAT
16 GND
17 GND
18 GND
19 GND
20 VC3.0
21 GND
22 V_ANT
23 GND
24 GND
25 GND
26 GND
27 GND
28 GND
29 GND
30 GND
31 GND
32 GND
33 GND
34 GND
35 GND
36 GND
37 Vcca
38 Vcca
39 GPIO3
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
I/O Description
I Power for RTC and SRAM
Digital ground
Digital ground
Digital ground
Digital ground
O Supply voltage of RF section
Digital ground
Power supply for an active
I
antenna
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
Digital ground
O
Control output for RF part
O Control output for RF part
I/O See chapter
VERSION 1.02
Level
+3 V DC ±5%
+ 3.0 V DC /
max. 25 mA
Up to +12 V DC/
max. 25 mA
+ 2.85 V DC /
max. 25 mA
+ 2.85 V DC /
max. 25 mA
6.8.4 CMOS
Page 29
